GA7004 = Digital Thickness Gauge 25mm / 0.1mm

The SnapThick digital thickness gauge has an LCD 3-Way readout (Inches - MM - Fractions) with a capacity of 0-1" / 0-25mm. One of the many features of this gauge is it’s easy to read LCD display screen for quick and accurate readings at a glance. Another feature of the gauge is a HOLD button to lock the reading of the measurement taken.

The instrument is light and compact in size, fits comfortably in the palm of your hand with fingertip measuring. It can be used in many applications from model making, quality control, jewelry making, and hobby.

Measuring Applications:

• Quality Control
• Small parts
• Sheet Metal
• Machinery parts
• Model Parts to Scale

Specifications:

• 3-Way Reading functions: Inch, Metric & Fractional
• Range:   0 - 1" - 0 - 25mm
• Resolution: 0.001" / 0.1mm / 1/64"
• Power saving: auto off feature
• Large LCD display: (Dimensions 1" - 25mm X 7/16"-11.2mm)
• Zero Setting: Button
• Hold: Button
• Lightweight and compact
• Spring Loaded
• Jaws: Alloy - Chrome Finished
• Battery: 3V CR2032 (Extra Included)
• Battery Life: Approximately 1 Year
• Gauge Diameter: 1-15/16" - 50.0mm
• Overall Measurements: Length 3-1/2" Width 2-3/4" Thickness 7/8" (Approx.)
• Net Weight: 4oz. - 100gr
